Journal Club | Efficient and non-polluting membrane to remove organic pollutants

A selective separation catalysis membrane removes and breaks down hydrophobic organic pollutants in water and soils efficiently while also limiting the amount of environmentally harmful catalytic by-products.
Journal Club | Efficient and non-polluting membrane to remove organic pollutants

Read the paper

Selective Separation Catalysis Membrane for Highly Efficient Water and Soil Decontamination via a Persulfate-Based Advanced Oxidation Process

The application of sulfate radical advanced oxidation for organic pollutant removal has been hindered by some shortages such as the recycling difficulty of a powered catalyst, the low utilization efficiency of oxidants, and the secondary pollution (including soil acidification) after reaction. Herein, we fabricate a selective separation catalysis membrane (SSCM) for a highly efficient and environment-friendly persulfate-based advanced oxidation process. The SSCM comprises a top polydimethylsiloxane layer which is selectively penetrable to hydrophobic organic pollutants, followed by a catalyst layer with a magnetic nitrogen-doped porous carbon material, targeting the advanced oxidation of the selected pollutants. Compared with the catalyst in powder form, such SSCM devices significantly reduced the dosage of peroxymonosulfate by more than 40% and the catalyst dosage by 97.8% to achieve 80% removal of phenol with the coexistence of 20 mg L–1 humic acid (HA). The SSCM can extract target pollutants while rejecting HA more than 91.43% for 100 h. The pH value in the receiving solution demonstrated a significant reduction from 7.01 to 3.00. In comparison, the pH value in the feed solution varied from 6.05 to a steady 4.59. The results can be ascribed to the specific functionality for the catalyst anchored, natural organic matter isolation, and reaction compartmentation provided by SSCMs. The developed SSCM technology is beneficial for catalysts reused in remediation practices, saving oxidant dosage, and avoiding acidification of soil and water, thus having tremendous application potential.

Hydrophobic organic pollutants bond strongly to sediments, in this way they can remain in water and soils long after the original source has been removed. A recent publication in Environmental Science & Technology now reports a selective separation catalysis membrane which overcomes the limitations of sulphate advanced oxidation processes, thus harnessing the processes for organic pollutant removal in an environmentally friendly way .

The sulphate radical advanced oxidation process is efficient, easy to implement and capable of oxidizing in a wide pH range.  But it has limited practical application, mainly because of the toxic byproducts due to excessive oxidant salts and oxidative sulphate product which pollutes the contacting water.  [1] Coupling the oxidation chemistry with catalyst membranes could lead to safer implementation in wastewater and soil treatment . [2]

Catalytic membrane based processes have attracted substantial interest because they are capable of combining the functions of reaction and separation processes in one step. The catalysts anchored in the membrane improve the reagents sorption and the membrane excludes other compounds from interfering. [3] However, the membrane pores are often blocked by impurities in water and soil washing solution, such as natural organic matter, resulting in a steep decline of catalytic activity. The possible leaching of oxides and byproducts into the contact water also constrains its utilization in flow-through systems. [4]

Baoliang Chen and his group from Zhejiang University designed a new selective separation catalysis membrane to remove the organic pollutants from water and soil.  The membrane overcomes the limitations of persulfate oxidation processes by also removing toxic by-products which would otherwise harm aquatic life. The membrane is composed of four layers: selective, dense, catalyst and nonwoven layers. The first selective layer uses water-repellent polydimethylsiloxane as a barrier, which extracts the hydrophobic pollutants and excludes the natural organic matter and water molecules as well

The catalyst, a cobalt-coated nitrogen-doped porous carbon material, is constructed beneath the selective and dense layer, which protects the catalysts form the natural organic matter interference and increases the accessibility of the catalyst to the pollutants. In this way, the device achieved highly efficient reaction because of the concentrated reactants in the catalyst layer.  The three layers are supported on the non-woven fabric layer. Compared to the catalyst in powder form, the new catalytic membrane system achieved 80% removal of phenol, a typical hydrophobic organic compound, with more than 40% reduction in the peroxymonosulphate dosage and 97.8% reduction in catalyst dosage. The new device rejected 91.43% natural organic matter, humic acid in this case, for 100 hours – successfully protecting the sulphate radical advanced oxidation processes from the interference of natural organic matter. Meanwhile, toxic byproducts were isolated within this sequenced layer structure, thus avoiding pollution of the contacting water.

The new selective separation catalysis membrane demonstrates promising applications in environmental remediation, as it provides an approach to remove the organic pollutant that is cost-effective with less damage to the environment as a result of reduced toxic catalytic by-products. The researchers describe their findings as a new “strategy to integrate membrane technology with catalysts” for safe and efficient hydrophobic organic pollutant removal.

The original article can be found here:

Qiu, Z., Xiao, X., Yu, W., Zhu, X., Chu, C. and Chen, B., 2022. Selective Separation Catalysis Membrane for Highly Efficient Water and Soil Decontamination via a Persulfate-Based Advanced Oxidation Process. Environmental Science & Technology. DOI:


[1] Xia, X., Zhu, F., Li, J., Yang, H., Wei, L., Li, Q., Jiang, J., Zhang, G. and Zhao, Q., 2020. A review study on sulfate-radical-based advanced oxidation processes for domestic/industrial wastewater treatment: degradation, efficiency, and mechanism. Frontiers in Chemistry, p.1092.


[2] Duan, X., Yang, S., Wacławek, S., Fang, G., Xiao, R. and Dionysiou, D.D., 2020. Limitations and prospects of sulfate-radical based advanced oxidation processes. Journal of Environmental Chemical Engineering, 8(4), p.103849.


[3] Ozdemir, S.S., Buonomenna, M.G. and Drioli, E., 2006. Catalytic polymeric membranes: Preparation and application. Applied Catalysis A: General, 307(2), pp.167-183.


[4] Zhang, X., Zhang, L., Li, Z., Jiang, Z., Zheng, Q., Lin, B. and Pan, B., 2017. Rational design of antifouling polymeric nanocomposite for sustainable fluoride removal from NOM-rich water. Environmental Science & Technology, 51(22), pp.13363-13371.
