The benefit of studying sponges is the workspace. For me it was the coral reefs of Eilat. There, between and underneath corals, you will find a multitude of sponges in all shapes and colors.

Sponge species commonly found in the Gulf of Aqaba, Eilat, Israel.

Our study, as so often happens, started with an unplanned detour. My friend and colleague Boaz wanted to study magnetism in sponges. As a diligent researcher, he first set out to analyze trace elements as background. After in-depth statistical analysis, he was surprised to discover that one species, Theonella swinhoei, stood apart as a hyper-accumulator of two elements: arsenic and barium (Mayzel et al 2014).

While Boaz was deep in the realm of biostatistics, I was trying to figure out what I wanted to do with my PhD. Hearing Boaz’s results in our group meeting (Ilan Lab at Tel Aviv University), I suggested this might be a related to the sponge’s dense and diverse microbiome. This little suggestion launched four years of exiting research in collaboration with some great guys.

Associated bacteria of Theonella swinhoei. Long filamentous bacterium is Entotheonella sp. SEM taken by Prof. Ilan.

Initially, we roughly separated sponge and bacteria cells and were able to say the arsenic (and probably also the barium) was sequestered by the bacterial community (Keren et al 2015 ). This was a nice finding, but we wanted more. Because the arsenic and barium concentrations were so high, Boaz, Adi and I hypothesized that few bacteria will play a more prominent role in the sequestration, and since these elements are electron dense we would be able to find them using the backscatter mode in a scanning electron microscope. The first time we tried it, it was like turning on the Christmas tree lights. With lady luck on our side, not only did we discover that a single bacterial species was the accumulator of both elements; this bacterium, Entotheonella sp., had a very distinct morphology (filaments). In addition, the cherry on top, we discovered the bacterium was precipitating the elements intracellularly! This enabled us to separate a clean fraction of these bacteria for testing.

Arsenic and barium accumulation by Entotheonella sp. Image on the left shows the bacterium in the sponge. Middle image shows z-contrast, in which light color means denser elements (i.e. the arsenic and barium). Right image shows the mineral spheres inside the bacterium.

I was fortunate to have such great collaborators throughout the four years of research of the bacterium. Prof. Pokroy took an Entotheonella sp. sample to the European Synchrotron Radiation Facility within a week of that first image. There, he saw that barium is mineralized as barite and smaller peaks of unknown arsenic mineral. Subsequent diffraction analysis revealed that the crystalline arsenic was calcium arsenate. The presence of these minerals was also validated under cryo conditions in collaboration with Dr. Fakra.

The last piece of information was found during the review process. A reviewer asked for TEM images to localize the minerals within the cells. Those images revealed that the mineralization occurs on vesicles. Additionally, smaller vesicles in the periplasm of the bacterium could explain how the elements might be accumulated from the surrounding environment.

It has been an exciting four years of research and I got through them with a lot of hard work, some educated guesses, and help from my friends.

The original paper can be found here:

Sponge-associated bacteria mineralize arsenic and barium on intracellular vesicles. Ray Keren, Boaz Mayzel, Adi Lavy, Iryna Polishchuck, Davide Levi, Sirine C. Fakra, Boaz Pokroy, and Micha Ilan. doi:10.1038/ncomms14393
